BlackFriday Bundle ECUMASTER PMU-24 DL + USB to CAN Module

Black Friday Bundle – ECUMASTER PMU-24 DL + USB to CAN Module

State-of-the-art power management with 24 outputs and built-in logging

The ECUMASTER PMU-24 DL is the latest and most advanced power management module in the Ecumaster lineup. It combines all the advantages of the PMU16 and PMU16_DL, and adds 24 high-side outputs plus integrated data logging memory as standard.
It is a highly advanced solution designed for the most demanding circuit, rally and professional motorsport projects.

As part of this Black Friday promotional bundle, you receive:

• ECUMASTER PMU-24 DL – power management unit with 24 outputs and integrated data logging

• ECUMASTER USB to CAN Module – USB interface for communication and configuration via CANbus

ECUMASTER PMU-24 DL – ultimate power distribution and control

Compared to PMU16 and PMU16_DL, the PMU-24 DL offers:

• 24 programmable high-side outputs

• 256 MB of built-in memory for data logging

• even greater flexibility and scalability

• clear indication of each output state via 24 tri-colour LEDs

• full CAN 2.0 A/B communication and easy import/export of CAN data

It is the ideal choice for vehicles with complex electrical systems and a large number of consumers.

Key features and specifications of PMU-24 DL

Advanced high-side outputs

• 10 × 25 A high-side outputs (with PWM support)

• 6 × 15 A high-side outputs

• 8 × 7 A high-side power outputs

• 24 high-side outputs in total

Logging and diagnostics

• Integrated 256 MB data logger memory

• Logging frequency up to 500 Hz

• Recording of current, voltage and status for all outputs

• All logged data can be downloaded for later analysis

• Real-time clock for accurate timestamping of data

Protection, safety and special functions

• Total continuous current capability: 170 A

• Operating voltage: 6–22 V, with transient protection according to ISO 7637

• Temperature range: -40°C to +125°C (AECQ-100 Grade 1)

• Integrated 3D accelerometer/gyroscope

• Built-in “inertia switch” function in case of an accident

• 24 tri-colour LEDs – one per output, for clear status indication

• Up to 16 analogue inputs

• Easy access to CAN data (import and export)

Communication

• 2 × CAN 2.0 A/B

• Full compatibility with EMU, ADU, CAN keypads and external loggers

• Complete diagnostics and live monitoring via CAN

ECUMASTER USB to CAN Module – communication and configuration

The bundle includes the USB to CAN Module, which allows you to:

• connect your PC to the PMU-24 DL via CANbus

• configure channels, logic and protection thresholds

• download logged data from the PMU

• perform diagnostics and monitor parameters in real time

Key features:

• support for CAN 2.0A and CAN 2.0B

• status LED for quick diagnostics

• switchable 120 Ω terminator

• optional version with galvanic isolation (depending on specification)

Who is the PMU-24 DL + USB to CAN Black Friday Bundle for?

Ideal for:

• advanced circuit and prototype cars

• drift, rally, time attack and endurance builds

• vehicles with very complex wiring and many power consumers

• applications that require maximum number of outputs and professional data logging

• projects where safety, reliability and fast diagnostics are critical

Shipping restriction

Ecumaster brand products are not shipped to the USA, Canada and Mexico.
