Turbocharger TurboSystems HTS3057B2
HTS version created for lower boosts and quicker spool. Recommended boost up to 1.5 – 1.7bar. High performance turbocharger designed for heavy loads and high temperature. Dual ceramic ball bearing and machined from solid aluminium compressor wheel makes it durable and efficient solution for motorsport use.
- Power range:300-450 HP;
Compressor side:
- Compressor wheel:in-house made, reinforced 57/71 mm 6+6 blades machined from the solid aluminium;
- Intake:63mm (2,5″);
- Air outlet:51mm (2″);
Core:
- Bearings: dual ceramic ball bearings;
- Cooling: water cooling with 2 x M14x1.5 ports;
- Lubrication: AN4 oil inlet with integrated oil restrictor;
Turbine side:
- Housing:single scroll, 10cm2 AR: 0.73;
- Turbine wheel:custom design 60/55mm 9 blades;
- Flange: T3 single scroll;
- Exhaust connection:3″ V-band clamp;
Included Vband clamp and Oil drain flange
HTS version created for lower boosts and quicker spool. Recommended boost up to 1.5 – 1.7bar. High performance turbocharger designed for heavy loads and high temperature. Dual ceramic ball bearing and machined from solid aluminium compressor wheel makes it durable and efficient solution for motorsport use.
- Power range:300-450 HP;
Compressor side:
- Compressor wheel:in-house made, reinforced 57/71 mm 6+6 blades machined from the solid aluminium;
- Intake:63mm (2,5″);
- Air outlet:51mm (2″);
Core:
- Bearings: dual ceramic ball bearings;
- Cooling: water cooling with 2 x M14x1.5 ports;
- Lubrication: AN4 oil inlet with integrated oil restrictor;
Turbine side:
- Housing:single scroll, 10cm2 AR: 0.73;
- Turbine wheel:custom design 60/55mm 9 blades;
- Flange: T3 single scroll;
- Exhaust connection:3″ V-band clamp;
Included Vband clamp and Oil drain flange
